TSC MH 640 Label Printer

• Resolution:

  • 600 dpi (24 dots/mm): Provides ultra-high resolution for fine detail, ideal for small text, barcodes, and graphics.

• Printing Method:

  • Thermal Transfer & Direct Thermal: Supports both types of printing. Thermal transfer requires ribbon usage for durable prints, while direct thermal works without ribbons for shorter-term labels.

• Max. Print Speed:

  • 152 mm (6 inches)/sec: High-speed printing capability for fast label production in high-volume settings.

• Max. Print Width:

  • 104 mm (4.09 inches): Can accommodate a wide range of label sizes, with a maximum width of 4.09 inches, making it suitable for a variety of label types.

• Max. Print Length:

  • 2,540 mm (100 inches): Supports long-length printing, which is ideal for larger labels or continuous roll stock.

Enclosure and Build:

• Die-cast Print Mechanism and Base:
  • The printer is designed with a die-cast mechanism for durability and long-lasting performance, even in rugged environments.
• Bi-fold Metal with Large Clear Media View Window:
  • Provides easy media loading and monitoring with a clear window to view the media without opening the printer.

Physical Dimensions:

• Dimensions:

  • 276 mm (W) x 326 mm (H) x 502 mm (D)
  • 10.87 inches (W) x 12.83 inches (H) x 19.76 inches (D)
  • These dimensions indicate a compact yet sturdy design, suitable for industrial settings where space might be a concern.

• Weight:

  • 15.35 kg (33.84 lbs): The printer is solid and built for heavy-duty use, weighing nearly 34 lbs, which reflects its industrial-grade construction.
