TSC TDP-225 2-inch Direct Thermal Printer 203 dpi — 203 dpi (8 dots/mm), 6 ips (152 mm/s), Direct thermal only. The 2-inch TDP series prints direct thermal labels and wristbands (W models) with a 6.5" roll capacity, LCD display and Ethernet/USB as…
Competitive pricing for bulk and repeat orders. Share your quantity for the best quote.
The TDP-225 prints at 5 ips and is the first low-cost affordable compact 2-inch desktop printer to offer an optional LCD display for easy tracking of print job status. Other outstanding features include an inexpensive internal Ethernet adapter for easy integration into networks and an optional keyboard for printing labels in stand-alone or down-time situations. The TDP-324 is also available, featuring high resolution 300 dpi printing resolution and 4 ips print speed.
Designed with n
Healthcare Patient Tracking
Lab Sample Tracking
Information Labels
Medical Record Labeling
Jewelry identification and pricing
Work-in-Process Tracking
Dietary Labeling
Price Labeling
Inventory & Asset Management
Small Office or Home Office Mailing
| Printing | |
| Resolution | 203 dpi (8 dots/mm) |
|---|---|
| Print method | Direct thermal only |
| Max. print speed | 6 ips (152 mm/s) |
| Max. print width | 2.05" (52 mm) |
| Max. print length | 90" (2,286 mm) |
| Media | |
| Media width | 0.59" – 2.05" (15 – 52 mm) |
| Media types | Continuous, die-cut, black mark, fan-fold, notched |
| Label roll capacity | 6.5" OD roll; 1" core |
| Memory | |
| RAM | 8 MB SDRAM |
| Flash | 4 MB (microSD expansion up to 4 GB) |
| Connectivity | |
| Interfaces | Ethernet, USB, USB Host |
| Display | LCD with buttons |
| Software | |
| Printer language | TSPL-EZD (auto-switching emulation of major printer languages) |
| Fleet management | TSC Console |
| Options | |
| Cutter | Optional guillotine cutter (full/partial cut) |
Specifications based on manufacturer documentation (verified Sep 2026). Subject to change without notice.
Patient wristbands (TDP-225W/324W), pharmacy and lab labels, jewellery tags, shelf-edge labels, small-item labelling.
Compatibility is listed only where verified against manufacturer documentation. Not sure? Ask us with your printer model.
Warranty as per manufacturer terms applicable in India. Contact us for the warranty period of this model.
