TSC TTP-286MT 8-inch Industrial Barcode Printer 203 dpi — 203 dpi (8 dots/mm), 6 ips (152 mm/s), Thermal transfer / Direct thermal. The 8-inch TTP-286MT / TTP-384MT print labels up to 8.5" wide — so wide-format and lateral barcodes print without image rotation — on a…
Competitive pricing for bulk and repeat orders. Share your quantity for the best quote.
The TSC TTP-286MT is a high-performance industrial thermal transfer label printer, designed for demanding applications requiring both speed and high-quality printing. With its advanced technology and rugged design, the TTP-286MT is perfect for high-volume printing environments such as manufacturing, logistics, and product labeling. This 8-inch wide printer delivers superior performance in printing thermal transfer and direct thermal labels.
| Printing | |
| Resolution | 203 dpi (8 dots/mm) |
|---|---|
| Print method | Thermal transfer / Direct thermal |
| Max. print speed | 6 ips (152 mm/s) |
| Max. print width | 8.5" (216 mm) |
| Max. print length | 450" (11,430 mm) |
| Media | |
| Media width | up to 9.5" (241.3 mm) |
| Media types | Continuous, die-cut, black mark, fan-fold, notched |
| Label roll capacity | 8.2" (208 mm) OD roll |
| Ribbon | |
| Max. ribbon length | 600 m |
| Ribbon width | 4.3" – 10" (110 – 254 mm) |
| Memory | |
| RAM | 256 MB SDRAM |
| Flash | 512 MB (SD card expansion up to 32 GB) |
| Connectivity | |
| Interfaces | Ethernet, USB 2.0, USB Host, Parallel, RS-232, GPIO, Bluetooth |
| Display | Colour LCD touchscreen with buttons |
| Physical | |
| Construction | Die-cast aluminium frame |
| Software | |
| Printer language | TSPL-EZD (auto-switching emulation of major printer languages) |
| Fleet management | TSC Console |
| Options | |
| Cutter | Optional guillotine or heavy-duty cutter (full cut) |
| Warranty | |
| Warranty | 2-year limited (standard, as published by TSC) |
Specifications based on manufacturer documentation (verified Sep 2026). Subject to change without notice.
Pallet and drum labels, chemical GHS labels, A4-size compliance documents, textile and carpet tags, wide shipping labels.
Compatibility is listed only where verified against manufacturer documentation. Not sure? Ask us with your printer model.
Warranty as per manufacturer terms applicable in India. Contact us for the warranty period of this model.
