TSC TTP-323 2-inch Barcode Printer 300 dpi — 300 dpi (12 dots/mm), 3 ips (76 mm/s), Thermal transfer / Direct thermal. The 2-inch TTP series is a compact, affordable thermal transfer printer for small labels and wristbands with a double-walled clamshell body…
Competitive pricing for bulk and repeat orders. Share your quantity for the best quote.
Print Resolution: The TSC TTP-323 offers a 203 dpi print resolution, delivering clear and precise text, barcodes, and graphics for all types of labels.
Print Speed: The printer can print at a speed of up to 4 inches per second, making it a good choice for environments where moderate printing volume is required.
Media Compatibility: It supports a range of label sizes, from 1.0" to 4.3" in width, and is compatible with both thermal transfer and direct thermal printing. This gives users flexibility in choosing different label materials based on their needs.
Connectivity Options: The TTP-323 features a USB 2.0 interface for easy connectivity to PCs, as well as serial and parallel ports for versatile integration into existing systems.
Compact Design: The TTP-323 has a compact footprint, making it ideal for tight spaces and smaller work areas, such as retail counters or warehouses with limited room for large printers.
User-Friendly Interface: The printer is equipped with an easy-to-read LCD display and simple button controls, making it easy for operators to configure and manage print jobs without extensive training.
Durability and Reliability: The TTP-323 is built to be robust and reliable, designed to handle continuous printing tasks with minimal maintenance. Its durable construction ensures it can withstand regular use in various work environments.
Affordable Printing Solution: The TTP-323 is a budget-friendly option for businesses that need a reliable barcode printer without the high costs associated with industrial models.
| Printing | |
| Resolution | 300 dpi (12 dots/mm) |
|---|---|
| Print method | Thermal transfer / Direct thermal |
| Max. print speed | 3 ips (76 mm/s) |
| Max. print width | 2.13" (54 mm) |
| Max. print length | 40" (1,016 mm) |
| Media | |
| Media width | 0.59" – 2.36" (15 – 60 mm) |
| Media types | Continuous, die-cut, black mark, fan-fold, notched |
| Label roll capacity | 5" (127 mm) OD roll |
| Ribbon | |
| Max. ribbon length | 90 m |
| Ribbon width | 2.20" – 2.28" (56 – 58 mm) |
| Memory | |
| RAM | 4 MB SDRAM |
| Flash | 8 MB (microSD expansion up to 4 GB) |
| Connectivity | |
| Interfaces | Ethernet, RS-232, USB, USB Host, Bluetooth |
| Display | LCD or LED with buttons |
| Physical | |
| Construction | Double-walled plastic clamshell |
| Software | |
| Printer language | TSPL-EZD (auto-switching emulation of major printer languages) |
| Fleet management | TSC Console |
| Options | |
| Options & accessories | Guillotine cutter, peel-off module, standalone keyboard |
Specifications based on manufacturer documentation (verified Sep 2026). Subject to change without notice.
Jewellery and small product tags, pharmacy labels, wristbands, shelf labels, laboratory samples.
Compatibility is listed only where verified against manufacturer documentation. Not sure? Ask us with your printer model.
Warranty as per manufacturer terms applicable in India. Contact us for the warranty period of this model.
