TSC TTP 342M Pro Label Printer

1. Thermal Transfer & Direct Thermal Printing:

   • The printer supports both thermal transfer (using ribbons for longer-lasting prints) and direct thermal (no ribbon needed, ideal for short-term applications) printing modes.

2. High Resolution:

   • It provides a 300 dpi (dots per inch) print resolution, allowing for high-quality text, graphics, barcodes, and images. This higher resolution is particularly beneficial for printing fine text and small barcodes.

3. Fast Print Speed:

   • The TTP-342M Pro can print at speeds of up to 4 inches per second, which helps increase productivity and meet moderate-volume printing demands.

4. Print Width:

   • The printer supports a maximum print width of 4.25 inches (108 mm), making it compatible with various label sizes commonly used in industrial and business settings.

5. Media Handling:

   • It accommodates a wide range of media types, such as roll-fed labels, fan-folded labels, tags, and wristbands, with a media width range from 1 inch to 4.25 inches.

6. Connectivity:

   • The TTP-342M Pro includes multiple connectivity options like USB 2.0, Parallel, and Serial ports, allowing it to be easily integrated into different environments and systems.

7. Durability & Reliability:

   • Built for demanding environments, the TTP-342M Pro is designed to handle heavy-duty workloads while maintaining print quality and speed.

8. LCD Control Panel:

   • The printer features a user-friendly control panel with an LCD screen that displays useful information such as print status, error messages, and media settings.

9. Expandable Memory:

   • The TTP-342M Pro is equipped with 4MB Flash and 8MB DRAM, allowing it to store fonts, graphics, and label formats for fast and efficient printing.

10. Software Compatibility:

• It is compatible with popular label design software such as BarTender, NiceLabel, and TSC’s own software, enabling easy label creation and printing.

Specifications:

• Print Resolution: 300 dpi
• Print Speed: Up to 4 inches per second
• Print Width: Max. 4.25 inches (108 mm)
• Print Length: Max. 39.37 inches (1000 mm)
• Connectivity Options: USB 2.0, Parallel, Serial
• Memory: 4MB Flash, 8MB DRAM
• Media Size: 1.0” (25.4mm) to 4.25” (108mm) width, up to 39.37” (1000mm) length
• Media Types: Roll-fed, fan-folded, die-cut labels, tags, wristbands
• Power Supply: External 100-240V AC

Use Cases:

• Shipping labels
• Product labeling and packaging
• Barcode printing
• Inventory and asset tracking
• Wristbands for events or healthcare settings
